3 Axles Container Flatbed Semi Trailer
With the good quality and reputation, we have been authorized ISO,CCC certificates. We have our own factory which is a professional manufacturer with 500 employees. Our products has been popular in Southeast Asia, Middle East, Africa and South America and Russia.
Product Introduction
Product introduction
3 axles container flatbed semi trailer is used for loading container or dry cargos.
Main beams welded by advanced large-scale special welding machines automatically.
Tongyada brand and CCC/ISO9001 certificates approved.
We adopt famous brand parts for our trailers, ensuring good characters.
We are Chinese leading professional manufacturer from 1982, you can customize your own trailers, we design and manufacture as per your exact requirements.
Product description
Our 3 axles container flatbed semi trailer: The flatbed trailer is designed to transport different size containers, like 20ft,40ft, 45ft, 53ft containers in general. Of course, the gooseneck flatbed container semi trailer also transport common bulk cargoes when you need. Its axle, suspension, tires, even main frame can made as per clients’ requirements. We have professional technology team to support after sale service. They are in the industry more than 20 years on average. We are serious about after-sales service. Tongya automobile Co., Ltd. specialized in manufacturing various trailers, such as container trailers, low bed trailers and various tanker trailers, etc. with advanced automatic equipment and excellent quality control. With the good quality and reputation, we have been authorized ISO,CCC certificates. We have our own factory which is a professional manufacturer with 500 employees. Our products has been popular in Southeast Asia, Middle East, Africa and South America and Russia.
Product Specification
|
Model |
3 axles container flatbed semi trailer |
|
Overall size |
12,500mm*2,500mm*1,550mm |
|
Tare weight |
7,200kgs |
|
Payload |
45,000kgs, we can also design as per your requirements |
|
I Beam & Chassis |
Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 16mm, width 140mm; Middle Flange 8mm,Height 500mm, Bottom Flange 16mm, width 140mm |
|
Axle |
Tongya brand, 13T/axle |
|
Number of axles |
3 axles |
|
Suspension |
Heavy duty mechanical suspension |
|
Floor |
3mm diamond steel plate |
|
King Pin |
JOST brand 2” Bolt-in King Pin |
|
Landing Gear |
JOST brand Two-speed, manual operating, heavy duty landing gear |
|
Wheel Rim |
9.0-22.5, 13 pieces |
|
Tire |
12R22.5, 13 pieces |
|
Spare Tire |
2 units |
|
Twist Lock |
12 units |
|
Braking System |
WABCO RE 6 relay valve; T30/30+T30 Spring braking chambers; two pieces of 45L air tanks |
|
Painting |
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
|
Tool box |
One standard tool box (Size can be chosen freely)(equipped with 1 unit tire spanner, 1 unit gudgeon sleeve and 1 unit cranking bar) |
