Bulk Cement Tanker Semi Trailer For Powder
The cement tanker semi-trailer is mainly used to transport powdered materials such as cement, fly ash, calcium carbide powder, talcum powder, carbon black, as well as granular materials like rice grains and plastic particles.
Product Introduction
Bulk Cement Tanker Semi Trailer for Powder
The bulk cement tanker semi trailer advantages:
1.High Capacity: They can transport large quantities of cement, reducing the number of trips required and increasing efficiency.
2.Durability: Built from strong materials, they can withstand harsh transport conditions and the abrasive nature of cement.
3.Versatility: They can also transport a variety of other powdered materials, such as fly ash or flour, allowing them to adapt to different industries.
4.Cost-Effective: Transporting bulk cement in large quantities can reduce overall transportation costs compared to transporting smaller amounts.
5.Specially Designed: Designed for bulk materials, they ensure safe transportation of powdery substances and minimize leakage.
6.Easy Loading and Unloading: Equipped with an air compressor and diesel engine, they can achieve efficient loading and unloading processes, saving time and labor.
Specifications:
|
Type:
|
Bulk cement tanker semi trailer
|
|||
|
Usage:
|
Transport bulk cement, coal ash, mineral powder,etc
|
|||
|
MOQ
|
1 unit
|
|||
|
Weight:
|
Tare Weight
|
9 T
|
||
|
Loading capacity
|
42 T
|
|||
|
Total weight
|
51 T
|
|||
|
Dimensions:
|
Dimension
|
11000×2500*3800mm
(The final dimensions depend on the final design drawings) |
||
|
Tanker capacity
|
40m3 (40000L)
|
|||
|
Tanker body:
|
Design/welding technology
|
Heavy duty and extra durability designed;
welding by automatic Submerged-Arc processes. |
||
|
Tanker body
|
The tanker body made of 5mm thickness steel
|
|||
|
Bottom chassis
|
High strength Q345B steel
|
|||
|
Tanker shape
|
"V" shape
|
|||
|
Silo
|
1 silo
|
|||
|
Manhole:
|
2 pieces, (Diameter is 500mm)
|
|||
|
Discharge mouth
|
4 inch Discharge mouth or optical
|
|||
|
Safety pressure valve
|
Standard
|
|||
|
Discharge hose
|
8m with Hose carries, the length is according to customer requirement
|
|||
|
Air compressor
|
12m3 double-cylinder air compressor, Bohai brand (Chinese famous brand)
|
|||
|
Engine
|
Diesel Engine,Weichai 4102 engine (Chinese famous brand)
|
|||
|
Rear ladder and handrail
|
With, as the photos shows
|
|||
|
Retention volume
|
<0.3%
|
|||
|
Axle
|
3 axles *square axle with 13 tons capacity, FUWA brand (Chinese best brand)
|
|||
|
King Pin
|
2.00''(50#) bolting king pin, JOST brand,German brand,made in China
|
|||
|
Suspension
|
Heavy duty tri-axle suspension with equalizers, American design (high-strength type)
|
|||
|
Steel Spring
|
Six sets of reliable local brand, 10pcs leaf spring, 13mm thickness, 90mm width
|
|||
|
Landing legs
|
JOST brand type, manual operation landing legs with sand shoe
|
|||
|
|
Tire specs
|
12R22.5, Triangle brand (Chinese famous brand)
|
||
|
Rim
|
9.00-22.5,(Chinese famous brand)
|
|||
|
Number of wheel
|
13 pieces(including one spare wheel)
|
|||
|
Brake system
|
WABCO relay valve;
Four double and two single brake chamber; One unit of reliable local brand 45L air tank; Two units of reliable local brand standard coppery air-connector. |
|||
|
ABS system
|
Without(Can be choose freely,450 USD/set)
|
|||
|
Electrical:
|
One unit of 24V 7-pin ISO 1185 socket; LED light
(standard rear light, turn light, rear reflector, side light, side reflector etc.) |
|||
|
|
Painting
|
Sand blasting before painting;
one coats of primer, anti-corrosion; two coat of finish painting; color advised by client |
||
|
Marking
|
Standard (Can spray customer LOGO)
|
|||
|
Side Guard
|
Standard
|
|||
|
spare wheel carrier
|
Two set of heavy duty spare wheel carriers, including a riser.
|
|||
|
Tools box
|
One piece (1. 0*0. 5*0. 5m)
(equipped with 1 Tire spanner,1 gudgeon sleeve and 1 cranking bar) |
|||
|
Shipment terms:
|
Shipping by flat rack container, RO-RO or bulk cargo ship,depend on the port of destination
|
|||
|
Delivery time:
|
Production time 20 workdays after down payment
|
|||
Send an inquiry to contact us for exclusive services and preferential pricing.
We are a manufacturing factory and welcome you to visit us.
