China New Product High Strength 40M3 Tipper Truck With Good Price
40M3 tipper truck is a semi-trailer suitable for the transportation of bulk and scattered goods such as coal, ore, earthwork, and construction materials. 40M3 tipper truck can be divided into two categories according to their uses: one is heavy-duty and super-heavy dump trailer for off-highway transportation, which mainly undertake transportation tasks such as large-scale mines and projects, and are usually used in conjunction with excavators.
Product Introduction
China new product High strength 40M3 tipper truck with good price
40M3 tipper truck is a semi-trailer suitable for the transportation of bulk and scattered goods such as coal, ore, earthwork, and construction materials.
40M3 tipper truck can be divided into two categories according to their uses: one is heavy-duty and super-heavy dump trailer for off-highway transportation, which mainly undertake transportation tasks such as large-scale mines and projects, and are usually used in conjunction with excavators.
The other type of light and medium-sized ordinary 40M3 tipper truck for road transportation are mainly responsible for the transportation of loose goods such as sand, soil, and coal, and are usually used in conjunction with loaders.
Our 40M3 tipper truck adopts rear unloading methods, which can effectively improve the transportation efficiency of bulk cargo transported by the loader.
The frame and the longitudinal beam of the 40M3 tipper truck are welded with high-quality manganese plates, and the cargo box has two types: dustpan and rectangle. It has high strength, strong lifting force, good rigidity and toughness, strong bearing capacity and no permanent deformation.
Sophisticated craftsmanship: The main components of 40M3 tipper truck are processed by advanced equipment, the longitudinal beams are fully automatic submerged arc welding, and the axles and leaf springs are precisely assembled by an assembly machine.
Product Specification
|
Specification |
|
|
Model |
ZTY9407ZZX |
|
Type |
3 axles 40M3 tipper truck Semi-trailer |
|
Overall dimension |
8600*2490*3420mm |
|
Inside cargo box dimension |
7653*2300*1400mm |
|
Capacity of cargo box |
23.9m3 |
|
Main beam |
Beam height: 500mm Upper plate: 18mm Single Middle plate: 12 mm Down plate: 20mm |
|
Platform thickness |
8mm |
|
Side wall thickness |
6mm |
|
Material |
Carbon steel, Q345 |
|
Gross vehicle weight |
8500 kg |
|
Total weight |
40000 kg |
|
Lifting system |
HYVA brand |
|
King pin |
90# (3,5 inch) |
|
Support leg |
JOST C200 |
|
Axle |
FUWA brand, 3*13T |
|
Suspension |
Mechanical suspension 10pcs leaf spring |
|
Tire |
Triangle brand, 1100R20, 13pcs |
|
Rim |
8.0-20, 13 pcs |
|
Brake System |
30/30 type on each axle |
|
Spare wheel carrier |
01 pcs |
|
Tool box |
01 pcs |
|
Electrical System |
Chinese standard 24V lighting system |
|
Side Maker Lamp |
LED lamp |
Send inquiry Contact Supplier For Exclusive Services And Preferential Price.
We are factory manufacturing, welcome you to visit our factory.
