Container Semi Trailer
Container semi trailer is mainly for containers transportation, it can be customized:
1-trailers can be for 20FT, 30FT, 40FT, 45FT, 48FT, 50FT, 53FT container shipping
2-flatbed or skeleton chassis type
3-Main beam: 500mm height
4-material of the main beam: Q345
5-Suspension: Spring suspension, Rigid, single point, bogie or air suspension
6-Axles number: 2 3 4 axles.
8-Jost landing gear, FUWA axles and Tri-angle tires
9-extendable or sliding type optional
Product Introduction
Main Features
Customized Container Semi Trailer, offer the container trailers to maximize the payload. TONGYADA brand skeleton container trailer adopt advanced design concept. After fully understanding and analysing the transportation environment in different countries. Also the length of the trailers can be customized, like 45ft, 48ft, or 53ft container transportation trailers.
TONGYADA Container semi trailer is designed for stevedoring and transporting 1x40', 1x 20'or 2x20'ISO Cargo Containers and loose cargos. To make sure the servise life of the semi trailers, all the apare parts we adopt are World Famous brand. We use famous German WABCO braking valve will definitely shorten the Braking Distance, to make the safety of the trailers and the drivers. Also the trailers floor is checker plate, this will keep the other bulk cargo more stable, like the bags, or long stuff.
Technical information
Terms | Container semi trailer supplier | |
Loading Capacity | 40tons | |
Axle | 3 axles ,TONGYADA axle | |
Tyre | 12 pieces,12R22.5 | |
Dimensions(LxWxH) | 12500mm x 2500 x 1550mm | |
Tare weight | 7tons | |
Axle spacing | 1310mm | |
Rims | 9.0-22.5 | |
Suspension System | Leaf spring Suspension | |
Brake System | Dual line pneumatic brake system with WABCO emergency relay valve | |
Main Beam | Height 500mm Q345 carbon steel | |
Chassis | upper 14mm, lower 16mm. Mid web 8mm | |
Kingpin | 2' or 3.5' interchangeable,JOST brand | |
Twist locks | 12 units ISO brand | |
Landing Gear | 28 Tons , Two speed manual operation | |
Electrical System | 1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) German standard | |
Lights and Reflectors | Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light | |
Painting | Shot blast to SA 2.5 Standard prior to application of primer, polyurethane top coat. Total DFT not less than 100μm;Any color will be available | |
Tool Box | One tool box with a set of standard trailer tools | |
Spare Tyre Carrier | One piece or two pieces | |
TONGYADA 3 axle 40 feet container semi trailer is mainly used in ships, ports, routes, roads, transit stations, bridges, tunnels, matching multimodal logistics system.
Specifically for a variety of container transport, customers can choose according to their own needs to change how many locks that may, all the accessories have been 20 years of experience in the use of supplier of choice, long-term repeated use, with sufficient strength
Container chassis semi trailer fast loading and unloading, and can be directly and easily from one vehicle to another vehicle facelift.
Order information
1, Payment terms: T/T or L/C.
2, Delivery time: Within 15 days after receipt the deposit
3, Packing: In nude with wax painting before deliver to port
4, Shipment type: By bulk ship, Ro-Ro or container
