Rear Tipper Trailer

The rear tipper trailer is a vehicle used for the transportation of bulk and scattered goods such as coal, ore, and construction materials, and is lifted from the front side.

Send Inquiry

Product Introduction

Product introduction

The steel of Rear Tipper Trailer is made of high-strength steel customized by large domestic steel mills, which has the characteristics of good stability. Secondly, our side guards, spare tire frames, fenders, etc. are made modular, which is more convenient and practical; Shot peening treatment, eliminating welding stress, more thorough rust removal, stronger paint adhesion. Finally, if you are interested in our products, please contact us in time.

Product Feature

The main purchasing parts of Rear Tipper Trailer is chosen from domestic famous brands and have passed CCC certification for reliable quality. Secondly, our hydraulic system uses big brands, which is more stable and reliable in quality. What's more, our auxiliary longitudinal beam is bent by large bending machine as a whole, and the strength of auxiliary frame is higher. Finally, our backward turning mechanism adopts Z-type box structure, which has higher strength and more stable lifting.

1(001)

Product Specification

Rear tipper trailer Specification
Product name	Rear Dump Trailer
Material	Q345B carbon steel
Color	Customers Optional
Usage	Transport Bulk Cargo,Transport sand,stone
Main Beam	Q345B carbon steel “H” beam
Lifting System	HYVA Brand
Loading capacity	80tons
Tare weight	8.5tons
Painting	Sand Blasting, Anti corrosive Prime
Dimension	9500X2500X3700mm
Floor	6mm Checkered Plate
Lighting	LED Light
Suspension	Mechanical Suspension
Axle	16 Ton Fuwa/BPW
Tire	12R20
Landing Gear	Standard 28Ton
King pin	3.5"(90mm)
Brake System	Dual Line Braking System
Rim	8.0-20
Leaf Spring	90(W)mm16 (Thickness)mm10(Layer)
