China Factory TONGYA Brand U Shape 3alexs HYVA Hydraulic Lifting Cylinder Super-link Side Dump Trailer For Sale
The super-link side dump trailer is a vehicle used for the transportation of bulk and scattered goods such as coal, ore, and construction materials, and is lifted from the front side. When used for off-road transportation, it mainly undertakes transportation tasks such as large-scale mines and projects, and is usually used in conjunction with excavators. When used in road transportation, the super-link side dump trailer mainly undertakes the transportation of loose goods such as sand, soil, and coal, and is usually used in conjunction with loaders.
Product Introduction
China Factory TONGYA brand U shape 3alexs HYVA Hydraulic lifting cylinder super-link side dump trailer for sale
The super-link side dump trailer produced by tongya Tops Intelligent Equipment has sophisticated technology, durability, high strength, strong lifting force, good stiffness, toughness, strong bearing capacity, and no permanent deformation.
Send inquiry Contact Supplier For Exclusive Services And Preferential Price.
We are factory manufacturing, welcome you to visit our factory.
trailer for sale:
1. The steel for super-link side dump trailer adopts high-strength steel customized by large domestic steel mills, with good stability;
2. The main purchased parts are selected domestic well-known brands, and have passed CCC certification, and the quality is reliable;
3. The side protection, spare tire frame, fenders, etc. are made modular, which is more convenient and practical; Shot peening, eliminates welding stress, removes rust more thoroughly, and has stronger paint adhesion;
4. The hydraulic system of the super-link side dump trailer select the big brand, the lifting is more stable and the quality is more reliable;
5. The auxiliary longitudinal beam is made by the overall bending of a large bending machine, and the strength of the auxiliary frame is higher;
6. The unique 77-type sub-longitudinal beam is perfectly matched with the frame, which makes the center of gravity of the whole vehicle lower, and the close contact between the two makes the situation more stable;
7. The rear flip mechanism adopts a Z-shaped box structure, which has higher strength and more stable lifting.
So just trust us, our super-link side dump trailer has the world class quality.
China factory TONGYA brand U shape 3alexs HYVA Hydraulic lifting cylinder super-link side dump trailer for sale
Product Specifications:
|
super-link side dump trailer Specification |
|
|
Product name |
Side Dump Trailer |
|
Material |
Q345B carbon steel |
|
Color |
Customers Optional |
|
Usage |
Transport Bulk Cargo,Transport sand,stone |
|
Main Beam |
Q345B carbon steel "H" beam |
|
Lifting System |
HYVA Brand |
|
Loading capacity |
80tons |
|
Tare weight |
12tons |
|
Painting |
Sand Blasting, Anti corrosive Prime |
|
Dimension |
9500X2500X3700mm |
|
Floor |
6mm Checkered Plate |
|
Lighting |
LED Light |
|
Suspension |
Mechanical Suspension |
|
Axle |
16 Ton BPW |
|
Tire |
12R20 |
|
Landing Gear |
Standard 28Ton |
|
King pin |
3.5"(90mm) |
|
Brake System |
Dual Line Braking System |
|
Rim |
8.0-20 |
|
Leaf Spring |
90(W)mm*16 (Thickness)mm*10(Layer) |
