Container Transport Truck Tailer
Tongyada container transport truck tailer is special designed to carry various cargo containers. You can choose to transport one 20ft,40ft container or two 20 ft container at one time. The only difference is the number of locks required for specific transportation application.
Product Introduction
Tongyada container transport truck tailer is special designed to carry various cargo containers. You can choose to transport one 20ft,40ft container or two 20 ft container at one time. The only difference is the number of locks required for specific transportation application.
According to the customer the long-term destination, and customer location of welding process, the customer can choose bulk carrier(Three stacked, hanging off can be used directly after the goods to the port of destination.)
|
Dimension |
12,500*2450*1450mm(According to customer demand) |
|
playload |
40,000kg |
|
Tare weight |
65,000kg |
|
Tyre |
12R22.5 (specification can be Optional) |
|
Rim |
9.0-22.5 |
|
King pin |
JOST brand 2.0 or 3.5 inch bolts type |
|
Main beam |
Height: 520mm, upper plate thickness is 14mm |
|
Side beam |
25mm channel steel (Material is Q235B carbon steel) |
|
Cross beam |
80*40mm square tube(Material is Q235B carbon steel) |
|
Twist lock |
12sets Enhanced international universal twist locks |
|
Landing gear |
JOST |
|
Axle |
13ton*3 axle FUWA brand |
|
Suspension |
mechanical suspension |
|
Brake chamber |
4 units T30/30 spring brake chambers,2 units T30 brake chambers |
|
Emergency valve |
WABCO |
|
Light |
Tail lamp with turn signal, brake light & reflector, side lamp etc |
|
Tool box |
1set standard tool box( waterproof type) |
|
Spare wheel carrier |
1 pieces( Patent type) |
|
Accessory |
A set of tools,An instruction manual |
|
ABS system |
optional |
|
Color |
According to customer demand |
|
Painting |
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
Container transport truck trailerr is dedicated to all kinds of container transportation, can carry a 40 feet container, can also carry two 20 feet container at the same time, or a 20 ft container, customers can according to your own need to change the locks number. Beam using submerged arc welding, the trailer shot blasting derusting, pattern plate bottom is 3 mm thick, we can also according to the customer designated accessories suppliers purchasing abroad or in China..can be long-term repeated use, has the enough strength.
We can according to the different requirements of customers to design the trailer ,or tell us t Tell us what you use. we will give you design the corresponding models, meet the personalized needs of customers
