2 Axle Fuel Tank Semi Trailer
We are Chinese leading professional manufacturer from 1982, you can customize your own trailers, we design and manufacture as per your exact requirements. The tanker body welded by advanced large-scale special welding machines automatically. Water filled test ensuring the tank's high sealed and avoiding the oil leaking. We adopt famous brand parts for our trailers, ensuring good character.
Product Introduction
Products Description
Strong Flexibility
The 2-axle design gives the vehicle a small turning radius, making it suitable for navigating complex road conditions such as urban and rural roads. Its maneuverability surpasses that of multi-axle semi-trailers.
Double-Layer Tank Structure
The tank features a double-layer design, with an inner layer made of corrosion-resistant stainless steel or aluminum alloy and an outer protective layer. This effectively prevents liquid leakage and ensures transportation safety.
Efficient Oil Unloading System
Equipped with an advanced hydraulic oil unloading system, the vehicle supports fast unloading operations, reducing loading and unloading time while improving work efficiency.
Wave-Breaking Board Design
A wave-breaking board is installed inside the tank to minimize liquid movement during transportation, enhancing vehicle stability and protecting the tank structure.
Multiple Safety Protections
Equipped with an anti-static device to prevent hazards caused by static electricity.
The tank includes a pressure release valve to maintain internal pressure balance.
An emergency shut-off valve is installed to quickly stop liquid flow in case of an emergency.
Excellent Environmental Performance
The tank has superior sealing performance, preventing liquid evaporation and leakage. It meets environmental protection standards and is suitable for transporting chemical liquids and other substances with high environmental requirements.
2 Axle Fuel Tanker Semi Trailer
We are Chinese leading professional manufacturer from 1982, you can customize your own trailers, we design and manufacture as per your exact requirements.
The tanker body welded by advanced large-scale special welding machines automatically.
Water filled test ensuring the tank's high sealed and avoiding the oil leaking.
We adopt famous brand parts for our trailers, ensuring good character.
We have a variety of tanker smei trailer, specific detailed parameters, you can contact us, we will give you the most favorable price.Many friend from Africa like this type semi trailer, we also have other capacity of fuel tanker semi trailer, more information please contact me freely.
Products Spceifiacations
2 Axle Fule Tanker Semi Trailer Specifications:
Specification |
|
| Model | Oil Tanker Semi Trailer |
| Shape | Square Circular shape |
| Total Volume | 30,000 liters |
| Tank Body Material | 5mm Q235 steel |
| End Plate | 6mm Q235 steel |
| Manhole Cover | Aluminum Alloy Manhole Cover |
| Bottom Safety Valve | Aluminum Pneumatic |
| Discharge Valve | Diameter 4 inch |
| Compartment | 2 compartments |
| Main Beam | Welding design |
| Axle | 13T, 2axles, Tongya or FUWA brand |
| Landing Gear | JOST A300C |
| Suspension | Mechanical type |
| Kingpin | JOST brand, 2.0 inch |
| Tire | 12R22.5 Triangle brand |
| Rim | 9.0-22.5 |
| Pneumatic Brake | WABCO RE 6 relay valve; 2 pieces of 45L air tanks |
| ABS | Optional |
| Color | As per customers' requirement |
| Shipping Term | By bulk cargo carrier or RORO |
Send inquiry Contact Us For Exclusive Services And Preferential Price.
We are factory manufacturing, welcome you to visit our factory.
