Flat Bed Dolly Trailer
Flat bed dolly trailer, also known as flatbed truck, full trailer flatbed, full trailer, flatbed trailer, etc., it is an important tool for modern logistics and transportation.
Product Introduction
Product introduction
Flat bed dolly trailer is an indispensable tool in the field of logistics and transportation. It can play its unique advantages in mountainous or rugged road conditions, thus simplifying the difficulty of transportation and improving work efficiency. This trailer has high carrying capacity, and it can be pulled forward by a tractor such as a forklift or tractor. After spraying treatment, its surface is not only less rusty but also more wear-resistant. The heavy I-beam design can effectively improve the overall stability and flexibility, and can also add more auxiliary mechanisms or functional components according to your needs.
Product features
1. This trailer is suitable for short-distance turnover transportation of bulk goods in factories, docks, ports, warehouses and other fields.
2. Because the drawbar can swing flexibly relative to the body, this trailer can play more advantages in bad road conditions.
3. The metal frame has extremely strong bearing capacity and is not easy to rust or be corroded.
4. Wheels with unique patterns are not easy to wear and can run stably for a long time.
Product Specification
Model | Flat bed dolly trailer |
Size | (12000+2200)*2500*1500 (mm) |
Payload | 30000KG |
Main beam | Heavy duty I beam. |
Axles | 1/2 * 13ton capacity (Brand optional) |
Suspension | Mechanical suspension with leaf springs(Air suspension /bogie optional) |
Tire | 12R22.5 12pcs (Other size optional) |
Rim | 9.00-22.5 12pcs (Other size optional) |
Twist locks | 4 |
King pin | 2’’/3.5’’ bolt type |
Landing gear | 28 Ton two speed |
Braking system | Double air chamber ,brake valve,32L air tanks ;ABS optional |
Electrical | LED light , 7 ways ,24V |
Painting | Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting |
